Intelligent Holographic Flash Camera Compatible with CMOS or CCD
image sensors
Flexible switch between visible lens or infrared lens35K high-speed
imaging +350 million pixel ultra-clear resolution
LED light source
Flexible Light Source Configuration: For different raw
material, the Color LED illumination system can choose use
different spectrum for the illumination to increase the contrast
and increase the precision of information
acquisition. The LED illumination system has the cooling system, so
the system has the long lifetime, low energy consumption and high
performance.
Dedicated Image Processing Algorithm According to the
characteristics of material, use the shape and color combination
algorithm; For materials with
complex colors, the machine sorts materials more directly and
accurately by using HSV-changed color space sorting method.
High-Quality Solenoid Valve
Use High-quality,high-frequency,long service life ejecter, super
low air consumption guaranteed the biggest capacity, excellent
rejection output. For the different sizes and
characteristics of material particle, use the solenoid valve of
different sizes.
Simple Operation
Simple optical system design, precise automatic correction system,
combined with the well-designed human-
machine interface to simplify the complexity of machine
commissioning and use, ensuring the simple operation and the
machine is easy to learn and use.
Working Principles
Color sorting machine is a kind of high-precision machine equipment
for color sorting and classification of objects. It can detect and
distinguish the colors of objects through optical sensors and image
processing technology, and then separate them out. Color sorters
are widely used in food processing, agricultural products,
plastics, recycled waste, ores and seeds, providing many important
advantages for production and processing processes.
Color sorters play an important role in the production and
processing industry. It improves production efficiency, product
quality and sustainable development, and helps enterprises achieve
a win-win situation of scientific and technological innovation and
economic benefits. With the continuous development of science and
technology, the functions and application fields of color sorters
will continue to expand, and make greater contributions to
industrial upgrading and sustainable development.
The main components of the color sorter are feed hopper, vibrating
feeder, chute, light source, background plate, CCD lens, outlet
hopper, nozzle, air compressor, air tank, and filter.
Latest UHD imaging and analysis technology,high-speed
processing,accurate identification
*High level AI self-learning function,one-key automation,user
friendly interface,easy operation
*Multi-function,multi-purpose,widely used for rice
,cereal,plastic,chinese medicine
*High and specification ensures high stability,with high sorting
accuracy,small carry over and low energy
*Small and portable,saving space and delivery cost,small machine
but super function
*Imported ejectors,much smaller air consumption,and much better
carry over,esp.good for small materials like quinoa,chia,sesame....
*Option:Remote control by smart terminals like cellphone ,can
realize the off-site controls of the accuracy,production capacity
and halt of the machines
*Simple Effective-installation&Start-up&Commissioning
services;remote teaching and guidance via live video online through
internet to worldwide
Optoelectronic system
The Optoelectronic system is the core part of the color sorting
machine, which is mainly composed of an LED light source,
background plate, CCD lens, and related auxiliary devices. The
light source provides stable uniform illumination of the material
being tested and the background plate. The CCD lens converts the
reflected light of the material to be measured into an electrical
signal in the detection area. The background plate provides a
reference signal for the electronic control system.
Sorting system
The sorting system consists of accessories such as sorting cabinet,
nozzles, air supply. The nozzle has been experimentally proved that
the nozzle spacing and the number of nozzles are one of the key
factors affecting the accuracy of the color sorter.
Cleaning system
The cleaning system consists of cylinders, glass cleaning brushes,
and other components. Because some items come with the dust and
other impurities that may adhere to the glass during the color
sorting process. Once the dust and impurities are attached to the
window glass, the optoelectronic system may cause chain-chain
problems such as false detection, which will affect the color
sorting accuracy and carryover ratio.
Operating System
The large-screen wide-angle touch screen is used to preset multiple
color sorting modes for customers. And establish a friendly
man-machine interface, according to the specific conditions of
materials convenient and quick to achieve adjustment.
How can a color sorter benefit your business?
Multi Functional
This product can be used in agricultural, grain, oil, chemical,
pharmaceutical and other industries, especially suitable for
rice, tea,
beans, seeds,
grains, raisins, plastic, ore, peanut, pepper, and other color sorting
field.
High Efficiency
Compared with manual sorting, a color sorter machine is labor
saving, time saving, high efficiency with much lower processing
cost, it can dramatically improve material accuracy to bring
economic and social benefits for customers all over the world.
