Wenyao Advanced Software CCD Wheat Color Sorter With Imported Parts
Tamarind Seed Color Sorting Machine
The powerful AI algorithm ensures the processing speed and accuracy
of the wenyao color sorter, which is dependent on the
ultra-high-speed camera to capture images and achieve a lower
takeout ratio. Real-time monitoring and feedback capabilities help
customers quickly identify and resolve any potential issues. This
helps improve efficiency and reduce downtime in production.
Advanced Image Acquisition
With 162 million pixel, super high-resolution full color Toshiba
CCD camera, subtlest defect as 0.01mm*mm can be sorted out(Bad spot
value can be adjusted according to different materials and
customers' requirement, to meet different batch and impurities rate
sorting requirement)
Remote Control and One-Key Operation
Brand new anti-rust UV chute
Wide-angle design, anti-rust and non-toxic&harmless aluminium
alloy, in line with international safety standards, ensure he
smooth slide of the material, and reduce waste, and achieve the
maximization of capacity. Customizable according to different
materials.
Intelligent Imagine Processing System
High identification, scan speed up to 30,000 times per second real
time big data analysis can fullfil all complex algorithms.
Germany High Luminance LED Light
Shadowless LED lighting system, with high luminance, long life
source, precise detectioin,stable
frequency,which ensure high sorting accuracy
High-speed electromagnetic ejector
Imported metal magnetic levitated egector,passed 2 billion times
pressure test. Durable,fast response,precise detection, improve
accuracy, and reduce energy consumption.
High-speed transmission system
Ethernet access system,data standardization,gigabit
ethernet,high-speed transmission system, high-tech support TP/TCP
protocol, Internet remote maintenance function. It can process
configuration management, performance management,fault management
and security management.
Flexible mode wide application
Different materials, design the corresponding pattern. One machine
can achieve different materials' screening.(Meet the color sorting
requirement of hundreds of millions products such as agricultural
products, industrial products and other special materials)
Technical Parameters:
| MODEL | WYCS4-256 |
| Chutes(channels) | 4(256) |
| Sorting accuracy(%) | ≥99.9 |
| Carryover rate (bad:good) | ≥30:1 |
| Output(T/h) | ≥2 |
| Voltage | 180-240V/50Hz |
| Power supply(kw) | 2.3 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air consumption(L/min) | 1000-2400 |
| Air supply(Mpa) | 0.6--0.8 |
| Dimension(L*W*H) mm | 1854*1560*1840 |
| Weight(kgs) | 750 |
| Package | Plywood case |
| Package Size mm | 2160*1680*2060 |
INTELLIGENT OPERATION SYSTEM
Overall Large Screen HD Operation control panel, 1080P Super high
resolution,system more stable, more friendly
Human-Machine-Interface panel, which gives high sensitivity instant
fast repones in the industrial environment.
NEWLY SPECIAL SUPER WIDTH CHUTE DESIGN
Special technology chutes, applicable for universal materials,make
the transfer more steady, more capacity.
MECHNICAL RECONSTRUCTION
Reconstrution of the mechnical frame, the main part with special
material,balancing whole frame bearing, ensure the machine
integrity. Working with the updated mechanism, it strength the base
of the ultra-sorting.
SELF-DEVELOPED SPRAY VALVE
Self-developed spray valve, Self-developed high-performance spray
valve, super high rapid response to the Algorithm results. It can
continuously working 12billion+ times, extremely long life, with
low air consumption,master the core technology.
ILLIMITABLE SORTING POSSIBILITIES, START BY “ONE BUTTON” PRESSURING
Hundred of sorting profiles can be saved in machine machine, for
the variety products for sorting, subdivide the quality of agric
and sideline products illimitable sorting possibilities,“one
button”start, “one button”profiles exchange.
SHADOWLESS COLD LIGHT SOURCE,AUTOMATICA ADJUSTABLE
Extremely long life, low energy consumption intellligent shadowless
cold light source, orthogonal spectrum technology, make the image
more visiable, more accuracy detection; the output luminance of
light source are automatically adjustable, it make the lights more
stable with high quality. It is fully appliable for the camera to
see and detect.
Why Choose Wenyao Color Sorter?
1. Over 17 years experience which focus on sorter machine. One of
the most advanced manufacturer in Hefei, Anhui.
2. After-Sales service guarantee: We have a professional after
sales service team, one-to-one customer service to help customers
install and debug.
3. We have service station over Southeast Asia, cooperate reseller
in more than 100 countries.
4. Quality assurance of raw materials: the raw material we purchase
are certified qualified products.
5. Quality process assurance: We have been authorized by CE & ISO
quality management system, each process of production are under
strictly standard.
6. System test: Our technical engineers check the product
performance, even every part is subjected to rigorous aging test to
ensure that the factory products would being in full compliance
with customer requirements.
7. Shipping guarantee: We have professional packaging operation
team, independent export qualification to ensure product safety and
stability to reach customers in hands.
Support and Services:
Our Grain Color Sorter product comes with comprehensive technical
support and services to ensure smooth operation and maximum
performance. Our team of experienced technicians and engineers are
available to provide remote and onsite support, as well as training
and consultation to help customers optimize their sorting process.
Our technical support services include troubleshooting and
diagnosis of any technical issues, as well as recommendations for
repair and replacement of parts. We also offer regular maintenance
and calibration services to ensure that the machine continues to
operate at peak efficiency.
In addition to technical support, we also offer customization
services to meet unique sorting needs of our customers. This
includes developing custom software and hardware modifications to
enhance sorting accuracy and speed.
Our commitment to customer satisfaction means that we are always
available to answer any questions or concerns related to our
product. We strive to provide the highest level of support and
service to help our customers achieve their sorting goals.
FAQ:
Q: What is the brand name of this grain color sorter?
A: The brand name of this grain color sorter is WENYAO.
Q: What is the model number of this grain color sorter?
A: The model number of this grain color sorter is WYCS4-256.
Q: Where is this grain color sorter manufactured?
A: This grain color sorter is manufactured in China.
Q: Is this grain color sorter certified?
A: Yes, this grain color sorter is certified with CE.
Q: What is the minimum order quantity for this grain color sorter?
A: The minimum order quantity for this grain color sorter is 1.
Q: What are the payment terms for this grain color sorter?
A: The payment terms for this grain color sorter are T/T and L/C.
Q: What is the supply ability for this grain color sorter?
A: The supply ability for this grain color sorter is 50 sets per
month.
