High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter

Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter from wholesalers

    Buy cheap High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter from wholesalers
    • Buy cheap High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter from wholesalers
    • Buy cheap High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter from wholesalers
    • Buy cheap High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter from wholesalers

    High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter

    Ask Lasest Price
    Brand Name : WENYAO
    Model Number : WYCS4-256
    Certification : CE
    Price : 15000$-16000$
    Payment Terms : T/T;L/C
    Supply Ability : 50 SET/MONTH
    Delivery Time : 15 DAYS
    • Product Details
    • Company Profile

    High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter

    High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter

    Product Description:

    Multifunction Color Sorter Machine for Walnuts, Almond, Pistachio Separation

    *Nuts Defects Sorting through High Resolution 4096 Pixel CCD Camera,High Reliability And Long Life LED Light Source;

    *Efficient And Stable Software System, Intelligent Algorism, User Friendly Interface;

    *Better Sorting Accuracy, Lower Carryover, And Bigger Production Capacity;

    *SOC Platform To Realize Stable, Reliable, Ultra-Fast Mass Data Processing;

    *Nuts Colour Sorting With Expert Sorting Solution Realizes One Key Debugging


    Primary Working Principles of a Color Sorter Machine

    So, what’s the primary working principle of a color sorting machine? Let’s break it down:

    First, the CCD color sorter determines the light transmittance and color depth of the material in its feeding hopper by:

    • Taking high-definition pictures
    • Comparing the amplitude of the light source changes
    • Ejecting material that has an amplitude that exceeds the predetermined value

    Now, consider the second working principle: when the mechanical separations begin, the materials must be distributed evenly into each channel. Then, the CCD camera in the sorting cabinet will detect the steadily flowing product. Upon identifying unqualified materials, the main control machine activates the spray valve, and the rejected product accelerates into the defective hopper.

    Color sorters are integral to many businesses, particularly in the agricultural and food processing industry. For example, a color sorter can display seed images and swiftly sort through grains and harvested products with rapid efficiency, including:

    • Corn
    • Beans
    • Nuts
    • Fruits
    • Seeds
    • Peanuts
    • Plastic
    • Salt
    • Wheat
    • Tea
    • Dehydrated vegetables
    • Spices
    • Snacks
    • Oats
    • Coffee beans

    Technical Parameters:

    MODELWYCS4-256
    Chutes(channels)4(256)
    Sorting accuracy(%)≥99.9
    Carryover rate (bad:good)≥30:1
    Output(T/h)≥2
    Voltage180-240V/50Hz
    Power supply(kw)2.3
    Work Air Pressure(Mpa)0.2-0.3
    Air consumption(L/min)1000-2400
    Air supply(Mpa)0.6--0.8
    Dimension(L*W*H) mm1854*1560*1840
    Weight(kgs)750
    PackagePlywood case
    Package Size mm2160*1680*2060

    INTELLIGENT OPERATION SYSTEM

    Overall Large Screen HD Operation control panel, 1080P Super high resolution,system more stable, more friendly Human-Machine-Interface panel, which gives high sensitivity instant fast repones in the industrial environment.

    NEWLY SPECIAL SUPER WIDTH CHUTE DESIGN

    Special technology chutes, applicable for universal materials,make the transfer more steady, more capacity.

    MECHNICAL RECONSTRUCTION

    Reconstrution of the mechnical frame, the main part with special material,balancing whole frame bearing, ensure the machine integrity. Working with the updated mechanism, it strength the base of the ultra-sorting.

    SELF-DEVELOPED SPRAY VALVE

    Self-developed spray valve, Self-developed high-performance spray valve, super high rapid response to the Algorithm results. It can continuously working 12billion+ times, extremely long life, with low air consumption,master the core technology.

    ILLIMITABLE SORTING POSSIBILITIES, START BY “ONE BUTTON” PRESSURING

    Hundred of sorting profiles can be saved in machine machine, for the variety products for sorting, subdivide the quality of agric and sideline products illimitable sorting possibilities,“one button”start, “one button”profiles exchange.


    SHADOWLESS COLD LIGHT SOURCE,AUTOMATICA ADJUSTABLE

    Extremely long life, low energy consumption intellligent shadowless cold light source, orthogonal spectrum technology, make the image more visiable, more accuracy detection; the output luminance of light source are automatically adjustable, it make the lights more stable with high quality. It is fully appliable for the camera to see and detect.


    Why Choose Wenyao Color Sorter?

    1. Over 17 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.

    2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.

    3. We have service station over Southeast Asia, cooperate reseller in more than 100 countries.

    4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.

    5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.

    6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.

    7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in hands.


    Support and Services:

    Our Grain Color Sorter product comes with comprehensive technical support and services to ensure smooth operation and maximum performance. Our team of experienced technicians and engineers are available to provide remote and onsite support, as well as training and consultation to help customers optimize their sorting process.

    Our technical support services include troubleshooting and diagnosis of any technical issues, as well as recommendations for repair and replacement of parts. We also offer regular maintenance and calibration services to ensure that the machine continues to operate at peak efficiency.

    In addition to technical support, we also offer customization services to meet unique sorting needs of our customers. This includes developing custom software and hardware modifications to enhance sorting accuracy and speed.

    Our commitment to customer satisfaction means that we are always available to answer any questions or concerns related to our product. We strive to provide the highest level of support and service to help our customers achieve their sorting goals.


    FAQ:

    Q: What is the brand name of this grain color sorter?

    A: The brand name of this grain color sorter is WENYAO.

    Q: What is the model number of this grain color sorter?

    A: The model number of this grain color sorter is WYCS4-256.

    Q: Where is this grain color sorter manufactured?

    A: This grain color sorter is manufactured in China.

    Q: Is this grain color sorter certified?

    A: Yes, this grain color sorter is certified with CE.

    Q: What is the minimum order quantity for this grain color sorter?

    A: The minimum order quantity for this grain color sorter is 1.

    Q: What are the payment terms for this grain color sorter?

    A: The payment terms for this grain color sorter are T/T and L/C.

    Q: What is the supply ability for this grain color sorter?

    A: The supply ability for this grain color sorter is 50 sets per month.
