High Capacity 640 Channels Plastic Granules Pellet Sorting Machine
Color Separating For Plastic
What is a CCD in a camera?
Stands for "Charged Coupled Device." CCDs are sensors used in
digital cameras and video cameras to record still and moving
images. The CCD captures light and converts it to digital data that
is recorded by the camera. For this reason, a CCD is often
considered the digital version of film.
Working principle:
Raw Material are put into the machine from its feeding hopper on
the top, vibrated by vibration device and sliding along material
chute into the zone of observation in sorting chamber through
sensor and background plate.Under the effect of light source, CCD
sensor receives compound light from materials being
sorted.According to the light intensity and color changes,make the
system produce output signal and drive solenoid valve to work
,ejecting the discolor grain to defect chamber and good materials
continue to fall into the finished goods chamber.
Wenyao all products technical parameters:
Color Sorting Machine Features:
1. The color high resolution CCD image acquisition system uses the
color CCD image acquisition system to realize the comprehensive
acquisition of the material red, green and blue color information.
The color sorter has the human eye's sense ability, the material
selection is more realistic and more in line with the requirements;
the higher resolution is up to 0.04 mm2, which can accurately
identify the fine defects and spots of raw materials. High
precision special lens ensures clear and accurate image.
2. Flexible and variable light source equipped with LED system with
heat dissipation, long life, low energy consumption and good
performance. Different raw materials require different spectral
lighting, and tailor the light source according to the needs of
customers.
3. The special image processing algorithm uses shape and color
combination algorithm according to material characteristics. For
complex color materials, the color space after HSV transformation
is more intuitive and precise.
4. Unique material trough equipped with special anodizing process
can ensure the output and make the product reach the international
level. It can be equipped with waterfall flat and narrow chute
channel, which can meet many kinds of material color selection.
5.High-quality solenoid valves use high-quality solenoid valves,
high frequency, long service life, very low gas consumption, to
ensure that the machine output is large, take-out ratio is low,
failure rate is low, low energy consumption; in view of the
characteristics of large and small particles of raw materials,
solenoid valves of different sizes are adopted.
6. Excellent rejection rate (take-out ratio 10:1). Advanced image
acquisition system + intelligent image processing algorithm + high
quality nozzle system = Excellent rejection rate
7. Simple operation, easy to learn and use, simple optical system
design, precise automatic correction system, combined with
carefully designed man-machine interface, greatly simplifies the
complexity of machine debugging and use, ensures simple operation,
and makes the machine easy to learn and use.
8. The selected material enters the machine from the top hopper,
slides down the channel through the vibration of the vibrator
device, accelerates the falling into the observation area of the
sorting room, and passes through the sensor and the background
plate. Under the action of light source, according to the intensity
and color change of light, the system generates output signal to
drive the solenoid valve to work and blow out the heterochromatic
particles into the waste cavity of the hopper, while the good
selected materials continue to fall into the finished cavity of the
hopper, so as to achieve the purpose of sorting
Effects of plastic sorting by wenyao color sorter:
Color sorter used in other materials:
Note:Our multi-functional color sorter can be used to sort rice,
wheat, peanuts, beans, nuts, tea, plastics, minerals, etc. The
following pictures are the color sorting performance of rice,
soybean,wheat, peanuts and almond.If you want to sort other
materials, please Contact our customer service, they will send you
the corresponding pictures and videos
Our Service:
Before Sale
We will provide detailed solutions for your special requirement and
help you know more about our color sorter.
After Sale Service
We will test your products at your plant, training your staff, set
every file for customer to serve all round service, so as to ensure
your machine working under the best situations.
From the date of use machine, we can provide one year free
maintenance ( not the reason of vandalism and something unexpected,
excluding delicate fittings) and lifetime maintenance.
Engineers available to service machinery overseas, we also can
train technical staff for customers.We provide lifelong software
upgrade services for our customers for free.
6. Packing and Delivery:
Parking and delivery:
Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
Our customer's case:
