Groundnut Color Sorter Machine With CCD Colour Camera Peanut
Sorting Machine
Working Principles
The main components of the color sorter are feed hopper, vibrating
feeder, chute, light source, background plate, CCD lens, outlet
hopper, nozzle, air compressor, air tank, and filter.
Feeding system
It consists of feeding hopper, vibrating feeder, and chute. Raw
material enters into vibrating feeder from the feeding hopper, then
automatically be arranged into a series of continuous current line
by vibration and a guiding mechanism, and fall to a detection zone
at a constant speed after being accelerated by the chute. to ensure
that the material is clearly present in the sorting cabinet. The
feeding system also controls the capacity of the color sorting
machine in addition to the function of providing raw material.T
through the adjustment of the vibration amount of the feed hopper
flow control plate and the vibration hopper, the control of the
output of the color sorter per unit time can be realized.
Optoelectronic system
The Optoelectronic system is the core part of the color sorting
machine, which is mainly composed of an LED light source,
background plate, CCD lens, and related auxiliary devices. The
light source provides stable uniform illumination of the material
being tested and the background plate. The CCD lens converts the
reflected light of the material to be measured into an electrical
signal in the detection area. The background plate provides a
reference signal for the electronic control system.
Cleaning system
The cleaning system consists of cylinders, glass cleaning brushes,
and other components. Because some items come with the dust and
other impurities that may adhere to the glass during the color
sorting process. Once the dust and impurities are attached to the
window glass, the optoelectronic system may cause chain-chain
problems such as false detection, which will affect the color
sorting accuracy and carryover ratio.
Color sorter work principle:
Working principle CCD color sorter CCD digital camera to material
is adopted signal acquisition.Analyze the collected signals,
handling, comparison, to eliminate beyond the value of the
material.
Color selection process as shown:
Color sorter at work,Feed hopper in the material under the action
of vibrator is uniform distribution in each chute,The CCD signal of
the whereabouts of the material in testing,If it is found that
there are unqualified material or impurities in the material,The
startup ejector to blow the defective goods in the hopper.(Above
only for the working process of the diagram,The actual material
shall prevail.)
Examples of color sorting:
From Customer's Site :
FAQ
1. How to use the machine?
We will supply the Installation instructions or video and our
engineers will train your operators.
2. How long about the guarantee period?
Two year. And we supply lifelong software upgrade services for our
customers.
3. Can you supply the air compressor, air tank and air filters?
Yes, we can provide above equipments, our standard offer includes
color sorter machine with air compressor, air tank and filters.
4. Is oversea service available?
Yes, our engineers could go abroad when required.
5.How to calculate Installation personnel cost?
On condition that customer requires to install, our company would
like to send 1 Engineer to guide for installation, then customer
should to pay the cost, including transaction of Engineer's visa,
transportation(air) for go abroad. and accommodation , local
transportation and security when the Engineer arrived.
Why choose US?
1. Over 15years experiences focus on color sorter. We have the strength give better service
and price to you.
2. Overseas Service Station: We have service station, cooperate reseller more than 40
countries. We can meet your requirements on testing, installation
and after sales service.
3. OEM/ODM is Supported: We have a strong R&G team. We can research and development
suitable color sorter for you.
4. Quality Process Assurance: We pass CE, RoHS and ISO quality management system, each process
of production are under strictly standard.
5. Shipping Guarantee: We have professional packaging operations team, independent
export qualification to ensure product safety and stability to
reach customers in the hands.
