100% Fully Automatic Intelligent 4 Chutes Nuts Sunflower Seeds Color Sorter Machine
When color sorter is working, feed hopper in the materials under the action of vibrator is uniform distribution in each chute. The CCD signal while the materials are dropping is in testing. If it is found that there are unqualified materials or impurities in the materials, the ejector will blow the defective goods in the hopper.
Technical Parameters:
MODEL | WYCS4-256 |
Chutes/Channels | 4/256 |
Throughput(t/h) | 2-3t/h |
Sorting Aaccuracy | ≥99.99% |
Power | 2.3kw |
Power Voltage | 180-240V/50Hz |
Air Source Pressure | 0.6-0.8Mpa |
Air Consumption | <2.4M3/Min |
Weight | 750kg |
Diamension(L*W*H) | 1855*1540*1852mm |
Color Sorter Working Principle:
Color sorter Definition :
One of the primary uses of an optical color sorter is to find blemishes in products, and remove unsatisfactory items from the manufacturing process. These flaws may be merely superficial, or they might indicate that a product is defective or unsafe. In a factory that produces a specific size item, for example, a defect or size variation with one of the products could cause significant problems. An optical sorter can detect the defect, and remove the improperly sized part before it is released from the factory.
Examples of color sorting:
Maintenance and inspection
1Monthly: check the filter element and the cleanliness of the ash
removing brush.
2Quarterly: check the fluorescent lamp.
3Half a year; check or replace lubrication oil for the compressor
at least one time.
Warning: in order to prevent static electricity and ensure the
personal safety, the host machine and its attached equipment shall
be in good ground connection. Electric cabinet opened by
professional only. It is forbidden to open the rear case cover of
the cabinet in operation as it is a fully enclosed automatic cycle
air cooling system.
