Sesame Color Sorter Grain Color Sorter Optical Sesame Bean Grain
Rice Colour Color Sorter
Color Sorter Technical Features :
| MODEL | WYCS6-384 |
| Chutes/Channels | 6/384 |
| Throughput(t/h) | 1-2t/h |
| Sorting Aaccuracy | ≥99.99% |
| Power | 3.1kw |
| Power Voltage | 180-240V/50Hz |
| Air Source Pressure | 0.6-0.8Mpa |
| Air Consumption | <3.2M3/Min |
| Weight | 1100kg |
| Diamension(L*W*H) | 2595*1540*1852mm
|
Color Sorter characteristic:
1.Automatic computing and intelligent identification with high
speed camera.
2.5400Pixel CCD image acquisition system with high speed chip.
3.Intelligent dust cleaning system,It means you can set cleaning
time and period according to your need.
4.Self design high frequency ejectors,It means high speed and
accurate sorting performance.
5.Low temperature LED light source system,Cooling system to make
the LED lamp more long life.
6.WIFI remote control system,It means color sorter connecting to the internet,You can use mobile
phone or computer to operate color sorter.
7.Easy to operate touch screen with english,spanish,german,russian
and so on more than 20 languages.
Below Our Strength:
1. With Over 14 years experiences.focus on sorter machine.
2.After-sales service guarantee: We have a professional after-sales
service team, one-on-one customer service to help customers install and w.
3.We have service station, cooperate reseller in more than 100 countries.
4.Quality assurance of raw materials: The raw materials we purchase are certified
qualified products.
5.Quality process assurance: We pass ISO quality management system, each process of production
are under strictly standard.
6.System test:Our technical engineers check the product performance, to ensure
that the factory products in full compliance with customer
requirements
The Color sorter work principle:
Working principle CCD color sorter CCD digital camera to material
is adopted signal acquisition.Analyze the collected signals,
handling, comparison, to eliminate beyond the value of the
material.
Color selection process as shown:
Color sorter at work,Feed hopper in the material under the action
of vibrator is uniform distribution in each chute,The CCD signal of
the whereabouts of the material in testing,If it is found that
there are unqualified material or impurities in the material,The
startup ejector to blow the defective goods in the hopper.(Above
only for the working process of the diagram,The actual material
shall prevail.)
Examples of color sorting:
From Customer's Site :
Frequently Asked Questions:
1. How to install and use the machine?
We will supply the Installation instructions or videos and our
engineers will train the operators.
2. How long about the guarantee period?
2 years. We supply lifelong software upgrade services for our
customers.
3. Can you supply air compressor, air tank and air filters?
Yes, We can provide above equipments, Our standard offer includes
color sorter machine with air compressor, air tank and filters.
4. How about after sales service?
Yes, By videos or by remote control or local service or engineers could go abroad when required.
5.Will you accept L/C as payment?
L/C ,T/T is OK.
6.Will you test machine before delivery ?
Yes , we will test carefully before delivey ,and save parameters in
the machine
Our main product is the Intelligent CCD Color Sorter. We have
developed dedicated & multi-function machines according to
customers different demands. At present we have created about 60
models of chute and belt type machines, which can separate rice,
tea, beans, seeds, small shrimps, nuts, grain, plastic, glass,
minerals and other materials.
Specialties Rice Color Sorter Machine, Small Rice Color Sorter,
Coffee Color Sorter Machine, Plastic Color Sorting Machine, Soybean
Color Sorter, Tea Color Sorter, Color Sorting Machine, Grain Color
Sorter, Wheat Color Sorter, Kidney Beans Color Sorter, Ccd Color
Sorter Machine,
we have great advantages in certain applications, for instance,
plastics, green mung beans, red beans, sparkled kidney beans, red
kidney beans, white kidney beans, black kidney beans, yellow beans,
soy beans, green beans, coffee beans, raisins, seeds, Chinese
herbs, dried prawn and shrimps, tuna fishes, and so on.
Regular maintenance and inspection
1Monthly: check the filter element and the cleanliness of the ash
removing brush.
2Quarterly: check the fluorescent lamp.
3Half a year; check or replace lubrication oil for the compressor
at least one time.
Warning: in order to prevent static electricity and ensure the
personal safety, the host machine and its attached equipment shall
be in good ground connection. Electric cabinet opened by
professional only. It is forbidden to open the rear case cover of
the cabinet in operation as it is a fully enclosed automatic cycle
air cooling system.
