Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min

Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min from wholesalers

    Buy cheap Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min from wholesalers
    • Buy cheap Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min from wholesalers
    • Buy cheap Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min from wholesalers
    • Buy cheap Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min from wholesalers

    Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min

    Ask Lasest Price
    Brand Name : WENYAO
    Model Number : WYCS2-128
    Certification : CE & ISO9001
    Price : Negotiable Price
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200PCS Per Month
    Delivery Time : 7-10 work days
    • Product Details
    • Company Profile

    Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min

    Bean Sorting Machine White Kidney Beans Intelligent Grain Color Sorter Machine


    Customized high definition RGB camera assembly can be installed for special material The latest 3 linear color CCD camera and FPGA processing system in addition to the high-speed electromagnetic ejector have been adopted in the machine, and also the multi-color touch screen has been installed therein, so it is a high-tech product combined with technology of optics, electronics and pneumatics. The machine can automatically reject contaminant or colored grains, featuring high sorting accuracy, great efficiency, simply operation, easy maintenance, compact structure and elegant appearance.


    Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min


    PARTS DETAILS:

    Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/MinIntelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min

    Color Sorter characteristic:

    1. Automatic computing and intelligent identification with high speed camera.
    2. 5400Pixel CCD image acquisition system with high speed chip.

    3. Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
    4. Self design high frequency ejectors,It means high speed and accurate sorting performance.
    5. Low temperature LED light source system,Cooling system to make the LED lamp more long life.

    6. WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.

    7. Easy to operate touch screen with english,spanish,german,russian and so on more than 20 languages.


    Technical Parameters:

    MODELWYCS2-128
    Chutes/Channels2/128
    Throughput(t/h)2-3t/h
    Sorting Aaccuracy≥99.99%
    Power1.1kw
    Power Voltage180-240V/50Hz
    Air Source Pressure0.6-0.8Mpa
    Air Consumption<1.2M3/Min
    Weight450kg
    Diamension(L*W*H)1250*1535*1832mm

    Examples of color sorting:

    Intelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/MinIntelligent 128 Channels Toshiba Bean Sorting Machine 1.2M3/Min


    1. What can you provide if we buy the machine?
    We will test here first(it is helpful if you can send us your material), after testing, we will send you a video to tech but if still have problem after you received it, we will send one engineer but it is paid.

    2. How long about the guarantee period?
    Two year. And we supply lifelong software upgrade services for our customers.

    3. Can you supply the air compressor, air tank and air filters?
    Yes, we can provide above equipments, our standard offer includes color sorter machine with air compressor, air tank and filters.

    4. Is oversea service available?
    Yes, our engineers could go abroad when required. but the cost need to be covered by Customer.

    5. How to calculate Installation personnel cost?
    Normally we will finish the installation here and if customer have special request, we will send 1 Engineer to teach, but customer need to cover the cost, including round -trip transportation and accommodation .
