4T/H Sacha Inchi Bean Sorting Machine with high sorting accuracy

Ask Lasest Price
Brand Name :	WENYAO
Model Number :	WYCS6-384
Certification :	CE & ISO9001
Price :	Negotiable Price
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	200PCS Per Month
Delivery Time :	15 to 20 working days

Add to Cart

Product Details
Company Profile

4T/H Sacha Inchi Bean Sorting Machine with high sorting accuracy

Sacha Inchi CCD Colour Sorter Machine Beans Color Sorter Color Sorting Machinery

MODEL	WYCS6-384
Chutes(channels)	6(384)
Sorting accuracy(%)	≥99.9
Carryover rate (bad:good)	≥12:1
Output(T/h)	≥4
Voltage	180-240V/50Hz
Power supply(kw)	3.1
Work Air Pressure(Mpa)	0.2-0.3
Air consumption(L/min)	1500-3200
Air supply(Mpa)	0.6--0.8
Dimension(LWH) mm	259515401852
Weight(kgs)	1100
Package	Plywood case
Package Size mm	264515901902

Ejector	Metal	1.High speed effect 1500times/second.2.Low air consumption 3.long time service.warranty:18 months.
Filter	YSC/CKD	1.High filtration accuracy 2.High filtering speed 3.durable and long time service.
Screen	Touch screen	1.Easy to operate with the man-machine interface 2.High sensitivity of the screen 3.The service life is long.4.Software update service program warranty:2 years
Hopper	304 stainless steel	1.Rust protection 2.Wear-resisting,wearproof
Package	Plywood case	1.Stable structure no deformation 2.Easy to transport

4T/H Sacha Inchi Bean Sorting Machine with high sorting accuracy

How does a color sorter work

The raw material enters the machine from the top hopper/storage hopper. Through the vibration of the vibrator device, the raw material slides down the channel accelerate down into the observation zone in the sorting cabinet and pass between the sensor and the background plate. Under the action of the LED light source, according to the intensity and color change of the light, the output signal of the system is driven to drive the solenoid valve to blow the heterochromatic particles into the waste outlet hopper, and the accepted material continues to fall to the finished product cavity of the acceptation outlet hopper. In order to achieve the purpose of color sorting.

Examples of color sorting:

4T/H Sacha Inchi Bean Sorting Machine with high sorting accuracy

From Customer's Site :

4T/H Sacha Inchi Bean Sorting Machine with high sorting accuracy

How can a color sorter benefit your business?

Multi-Functional

This product can be used in agricultural, grain, oil, chemical, pharmaceutical and other industries, especially suitable for rice, tea, sesame, beans, seeds, raisins, plastic, ore, peanut, pepper, and other color sorting field.

High Efficiency

Compared with manual sorting, a color sorter machine is labor-saving, time-saving, high efficiency with much lower processing cost, it can dramatically improve material accuracy to bring economic and social benefits for customers all over the world.

Color Sorter characteristic:

1.Automatic computing and intelligent identification with high speed camera.
2.5400Pixel CCD image acquisition system with high speed chip.
3.Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
4.Self design high frequency ejectors,It means high speed and accurate sorting performance.
5.Low temperature LED light source system,Cooling system to make the LED lamp more long life.

6.WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.

7.Easy to operate touch screen with english,spanish,german,russian and so on more than 20 languages.
