Pecan Nuts Color Sorter Machine For Separating Pecan Kernel And
Shell
1.Color sorter Principle as following:
Color sorter at work,Feed hopper in the material under the action
of vibrator is uniform distribution in each chute,The CCD signal of
the whereabouts of the material in testing,If it is found that
there are unqualified material or impurities in the material,The
startup ejector to blow the defective goods in the hopper.(Above
only for the working process of the diagram,The actual material
shall prevail.)
One of the primary uses of an optical color sorter is to find
blemishes in products, and remove unsatisfactory items from the
manufacturing process. These flaws may be merely superficial, or
they might indicate that a product is defective or unsafe. In a
factory that produces a specific size item, for example, a defect
or size variation with one of the products could cause significant
problems. An optical sorter can detect the defect, and remove the
improperly sized part before it is released from the factory.
2.Technical Parameters:
| MODEL | WYCS7-448 |
| Chutes/Channels | 7 / 448 |
| Throughput(T/h) | 5T/h-7T/h |
| Sorting Aaccuracy | ≥99.99% |
| Power | 3.9kw |
| Power Voltage | 180-240V/50-60Hz |
| Air Source Pressure | 0.6-0.8Mpa |
| Air Consumption | <2.8M3/Min |
| Weight | 1350kg |
| Diamension(L*W*H) | 2905*1540*1852mm |
How to get the correct size and suitable price of wenyao color
sorter machine?
Step 1.Which kinds of the material do you want to sort ?
Step 2.How much input capacity for the raw materials per hour?
Step 3.In order to know the impurity rate of the raw materials
which are needed to be sorted, please send us 3 pictures as
following:
1. Raw material picture(feeding in the machine materials)
2. Accepted material picture(you want to save the good materials)
3. Rejected material picture(you want to sort out the bad
materials)
3.Machine Features:
Features:
1.Most advanced RGB cameras with 5400 pixels linear industry CCD
sensor .
2.America FPGA processing chip.
3.Japan Toshiba CCD sensor.
4.Metal ejectors/valves with more than one billion lifetime
5.Lens:Japan Nikon Lens .
6.Filter: Japan CKD filter
7.Power source:Taiwan Meanwell
8.All LED light source,more longer lifetime and save power
9.Flexem Humanized touch screen
10. WIFI remote control system,help end user to debug and monitor
machine situation in chinese factory during covid-19 period,Supply
non-contactness after service
4.Examples of Color Sorting Examples
5.Our Service:
A:For software:We have installed WIFI remote control system on
machine,Once machine arrived in your local we will connect with
machine touch screen provide technical assistance from Chinese
factory.
B:For hardware:We will supply you the spare parts ship together
with machine,In case you face hardware problems,we will guide you
how to repair by live videos.
6.Packing and Delivery:
Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
Delivery Detail:
Within 15 - 20 days after received deposit.
7.FAQ
1. How to install and use the machine?
We will supply the Installation instructions or videos and our
engineers will train the operators.
2. How long about the guarantee period?
2 years. We supply lifelong software upgrade services for our
customers.
3. Can you supply air compressor, air tank and air filters?
Yes, We can provide above equipments, Our standard offer includes
color sorter machine with air compressor, air tank and filters.
4. How about after sales service?
Yes, By videos or by remote control or local service or engineers could go abroad when required.
