    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting

    Ask Lasest Price
    Brand Name : WENYAO
    Model Number : WYCS6-384
    Certification : CE & ISO9001
    Price : Negotiable price
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200PCS Per Month
    Delivery Time : 15 to 20 working days
    • Product Details
    • Company Profile

    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting

    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting


    Parameters as below:


    Main PartsParameters/ brandParts Advantage and warranty
    Channels64*6=3841.High quality aluminum alloy 2.Anodic oxidation 3.Surface polishing treatment 4.Material Slipping steadily 5.wear-resisting,wearproof 6.The service life is long.
    Pixel of camera54001.High accuracy 5400 pixels 2.High perfomance with high resolution.warranty:2 years
    CCD sensorToshibaHigh Sensitivity and resolution warranty:2 years
    Light sourceLED Lamps1.Luminous evenly 2.The service life is long 3.The light is not weak for long time

    EjectorMetal1.High speed effect 1500times/second.2.Low air consumption 3.long time service.warranty:18 months.
    FilterYSC/CKD1.High filtration accuracy 2.High filtering speed 3.durable and long time service.
    ScreenTouch screen1.Easy to operate with the man-machine interface 2.High sensitivity of the screen 3.The service life is long.4.Software update service program warranty:2 years
    Hopper304 stainless steel1.Rust protection 2.Wear-resisting,wearproof
    PackagePlywood case1.Stable structure no deformation 2.Easy to transport

    Technical Features :

    MODELWYCS6-384
    Chutes/Channels6/384
    Throughput(t/h)1-2t/h
    Sorting Aaccuracy≥99.99%
    Power3.1kw
    Power Voltage180-240V/50Hz
    Air Source Pressure0.6-0.8Mpa
    Air Consumption<3.2M3/Min
    Weight1100kg
    Diamension(L*W*H)2595*1540*1852mm

    Camera

    leading in the industry

    International well-known brand customized lens
    Import high-end 4096PIXEL CCD sensor
    High-speed of scanning
    The highest resolution comes to 0.02 mm²


    High-frequency Solenoid Valve

    leading in China

    High-quality high-frequency solenoid valve, with consistency of near zero error.

    Service life more than 1 billion times.
    Ultra high precision, leading in China


    Intelligent Image Processing Algorithm

    The combination of colors and shapes of

    intelligent algorithm
    Leading role in China.
    Precise professional sorting solutions


    Customized Lighting System

    import purchasing

    Advanced LED optical design system.
    Various light sources are available to suit different materials.
    Designated procurement of imported LED lamps,Higher stability, longer service life.
    LED lighting system with thermal dissipation.


    Data Transmission System

    high-speed and stable

    The COAX interface:
    High anti-jamming, high transmission speed, high stability


    Chip

    innovative ultra high-speed processing

    Based on SOC platform architecture;
    Compared to DSP platform, the CPU improves 5 times, output processing improves 4 times, realizing the stability ,reliability and high-speed mass data processing.


    Feed Trough

    special technology

    Application of high-quality 300mm ultra wide trough in China;

    Special anodization treatment process ensures the required production in line with the international first-class level;

    Cascading flat plate and narrow chute channel can be outfitted to sort a variety of material colors.


    Human-Computer Interface

    simple and easy to operate

    More intelligent, easy operation, one button for professional sorting, remote debugging, remote diagnosis, remote software upgrading.


    Application:


    Cereals:rice,millet,parboil rice,black rice,red rice,brown rice,thai rice,glutinous rice.
    Grains:peanut, corn,sesame,oat.
    Beans:red beens,kidney beans,coffee bean,black beans,mung beans.
    Nuts:walnut kernel,apricot kernel,sunflower seeds,almond,watermelon seed,macadamia nut.
    Industries:plastic,electronic component,industrial salt,quartz sand

    Rice: rice/brown rice/sticky rice/millet/sorghum/myotonin/black rice


    Our main product is the Intelligent CCD Color Sorter. We have developed dedicated & multi-function machines according to customers different demands. At present we have created about 60 models of chute and belt type machines, which can separate rice, tea, beans, seeds, small shrimps, nuts, grain, plastic, glass, minerals and other materials.

    Specialties Rice Color Sorter Machine, Small Rice Color Sorter, Coffee Color Sorter Machine, Plastic Color Sorting Machine, Soybean Color Sorter, Tea Color Sorter, Color Sorting Machine, Grain Color Sorter, Wheat Color Sorter, Kidney Beans Color Sorter, Ccd Color Sorter Machine,


    we have great advantages in certain applications, for instance, plastics, green mung beans, red beans, sparkled kidney beans, red kidney beans, white kidney beans, black kidney beans, yellow beans, soy beans, green beans, coffee beans, raisins, seeds, Chinese herbs, dried prawn and shrimps, tuna fishes, and so on.

    Our Strength:

    1. With Over 14 years experiences.focus on sorter machine.

    2.After-sales service guarantee: We have a professional after-sales service team, one-on-one customer service to help customers install and w.

    3.We have service station, cooperate reseller in more than 100 countries.

    4.Quality assurance of raw materials: The raw materials we purchase are certified qualified products.


    5.Quality process assurance: We pass ISO quality management system, each process of production are under strictly standard.
    6.System test:Our technical engineers check the product performance, to ensure that the factory products in full compliance with customer requirements



    Color sorter work principle:

    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting

    Working principle CCD color sorter CCD digital camera to material is adopted signal acquisition.Analyze the collected signals, handling, comparison, to eliminate beyond the value of the material.
    Color selection process as shown:

    Color sorter at work,Feed hopper in the material under the action of vibrator is uniform distribution in each chute,The CCD signal of the whereabouts of the material in testing,If it is found that there are unqualified material or impurities in the material,The startup ejector to blow the defective goods in the hopper.(Above only for the working process of the diagram,The actual material shall prevail.)


    Examples of color sorting:

    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color SortingNew Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting


    From Customer's Site :


    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting

    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color SortingNew Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting



    Frequently Asked Questions:

    1. How to install and use the machine?
    We will supply the Installation instructions or videos and our engineers will train the operators.

    2. How long about the guarantee period?

    2 years. We supply lifelong software upgrade services for our customers.
    3. Can you supply air compressor, air tank and air filters?
    Yes, We can provide above equipments, Our standard offer includes color sorter machine with air compressor, air tank and filters.

    4. How about after sales service?

    Yes, By videos or by remote control or local service or engineers could go abroad when required.
    5.Will you accept L/C as payment?
    L/C ,T/T is OK.

    6.Will you test machine before delivery ?

    Yes , we will test carefully before delivey ,and save parameters in the machine


    Packing And Delivery :

    New Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color SortingNew Design Optical CCD Small Garlic Color Sorter Manufacturer Multifunction Color Sorting


    Our Advantage:


    1. With Over 14 years experiences.focus on sorter machine.

    2.After-sales service guarantee: We have a professional after-sales service team, one-on-one customer service to help customers install and w.

    3.We have service station, cooperate reseller in more than 100 countries.

    4.Quality assurance of raw materials: The raw materials we purchase are certified qualified products.


    5.Quality process assurance: We pass ISO quality management system, each process of production are under strictly standard.
    6.System test:Our technical engineers check the product performance, to ensure that the factory products in full compliance with customer requirements
